Dimensions : (LxWxH) 62 mm x 169 mm x 82 mm (2.4? x 6.6? x 3.2?)
Weight : 130g (4.6 oz)
Input Voltage : 4.0 to 5.5 VDC
Operating Power : 2 W (400mA @ 5 VDC)
Scan Pattern : 1D, optional - Area Image (640 x 480 pixel array)
Motion Tolerance : Up to 10 cm/s (4 in/s) for 13 mil UPC at optimal focus
Scan Angle : Horizontal 37.8ø; Vertical 28.9ø
Symbol Contrast : 35% minimum reflectance difference
Pitch, Skew : ñ60ø, ñ70ø
Decode Capability 1450g1D: All standard 1D symbologies ,
1450g2D: All standard 1D, PDF417, and 2D symbologies
